The PL 150 Motorized Swing Gate Turnstile is designed as an elegant and alternative passage lane specifically for wheelchair users and VIP access. Constructed with a robust 304-grade stainless steel main body and a wing featuring 3 mm thick blue plexiglass, it is built for long-lasting use in indoor environments such as banks, ministries, and business centers. The turnstile operates bi-directionally, automatically opening 90° upon access approval from integrated devices like card or biometric readers. Furthermore, it ensures safety by keeping the wing open in both directions to allow free passage during a power outage.
Powefull Mechanism.
Elegant Design.
Long-lasting.
Disabled Access.
VIP Access.
Spare Parts Support.
LED and Logo Application.
| Feature | Details |
| Control/Operating Voltage |
100-230 VAC 50/60 Hz |
| Power Consumption |
30 W |
| Operating Temperature |
-10°C – +50°C |
| Passage Speed |
20-30 personn/munite |
| Weight |
25 Kg |
| Usage Areas |
Indoor |
| Body |
304 Stainless steel |
| Wing Length |
850 mm |
| Wing |
3 mm Blue Plexyglass |
| Optional Accessories |
Biometric reader, card reader, button, remote control |
Integration: Any access control device such as a card reader, biometric reader, remote control, or button can be connected via a simple dry contact.
Passage Operation: When access is granted, the PL 150 MSWG turnstile automatically opens 90°. It remains open for 15 seconds before closing and locking itself again. This open waiting time can be adjusted through PLC settings.
Emergency Safety: The turnstile is designed to keep the wing open in both directions in case of a power outage, allowing free passage. If the turnstile is optionally equipped with a battery, it will continue to operate in its standard mode for a certain period during a power failure.
Customization: Optionally, LED indicators can be added to the top cover, and logo application can be applied to the wings.
